RemovableMassStorage
3. Push File Utili
ties ► More ► Format.
4. Select Ye s to format the CF card.
CF Card Capacities
The oscilloscope can store t he following types and number of files per 1 MB of
CF card memory:
5 Save All operations. (See page 108, Save All.)
16 screen image files (capacity depends on the image format). (See page 109,
Save Image.)
250 oscilloscope setting (.SET) files. (See page 109, Save Setup.)
18 waveform (.CSV) files. (See page 110, Save Waveform .)
File Management Conventions
The o scilloscope uses the following file management conventions for mass
storage:
It checks for available space on the CF card before writing files, and displays
a warning message if there is not enough memory available
The term folder refers to a directory location on the CF card
The default location for the file save or file recall functions is the current folder
The root folder is A:\
The oscilloscope resets the c urrent folder to A:\ when you power on the
oscilloscope, or when you insert a CF card after the oscilloscope is powered on
File names can have one to e ight characters, followed by a period, and then
followed with an extension of one to three characters
It displays long file names created on PC operating systems with the shortened
file name from the operating system
File names are upper case
You can use the File Utilities menu to do the following tasks:
List the c ontents of the current folder
Select a file or folder
Navigate to other folders
Create, rename, and delete files and folders
Format the CF card
This manual contains more details on the Utility ► File Utilities menu. (See
page 119, File Utilities.)
82 TPS2000B Series Digital Oscilloscope User Manual
