Reference
Options Comments
Format
Formats the CF card; this deletes all data on the CF card
Update Firmwa
re
Follow the on-
screen directions to set up and push the Update
Firmware option button to start updating firmware.
Rename File
or Folder. You can change the names of files and folders on the
CF card.
Option Settings Comments
Enters the highlighted alphanumeric character at the
current Name field cursor position
A - Z, 0 - 9, _,
.
Use the multipurpose knob to select an alphanumeric
character or the Backspace, Delete Character, or Clear
Name functions
Backspace
Changes the menu button 1 option to the Backspace
function. Deletes the character to the left of the
highlighted character in the Name field
Delete
Character
Changes the menu button 1 option to the Delete
Character function. Deletes the highlighted character
from the Name field
Enter
Character
Clear Name Changes the menu button 1 option to Clear Name.
Deletes all characters from the Name field
Vertical Controls
You can use the vertical controls to display a nd remove waveforms, adjust vertical
scale and position, set input parameters, a nd for vertical math operations. (See
page 105, Math.)
Channel Vertical Menus
There is a separate vertical menu for each channel. Each option is set individually
for each channel.
Op
tions
Se
ttings
Co
mments
C
oupling
D
C, AC, Ground
D
C passes both AC and DC components of the
input signal
AC blocks the DC component of the input signal
a
nd attenuates signals below 10 Hz
Ground disconnects the input signal
120 TPS2000B Series Digital Oscilloscope User Manual
