Application Examples
This section presents a series of application examples. These simplified examples
highlight the features of the oscilloscope and give you ideas for using it to solve
your own test problems.
Taking simple measurements
Using Autoset
Using the Measure Menu to take automatic measurements
Measuring
two signals and calculating gain
Using Autorange to examine a series of test points
Using an isolated channel to analyze a differential communication signal
Viewing an instantaneous power waveform
Taking cursor measurements
Measuring ring frequency and ring amplitude
Measur
ing pulse width
Measuring rise time
Analyzing s ignal d etail
Looking at a noisy signal
Using the average function to separate a signal from noise
Capturing a single-shot signal
Opt
imizing the acquisition
Measuring propagation delay
Triggering on a pulse width
Triggering on a video signal
Triggering on video fields and video lines
Using the window function to see waveform details
Viewing impedance changes in a network using XY mode and persistence
TPS2000B Series Digital Oscilloscope User Manual 37
