Appendix B: TPP0101 and TPP0201 Series 10X Passive Probes Information
Table 12: Certifications and compliances (cont.)
Characteristics Description
Category Examples of Products in this Category
CAT III Distribution-level mains, fixed installation
CAT II
Local-level mains, appliances, portable equipment
Measurement
Category
Descriptions
CAT I Circuits not directly connected to mains.
Pollution Degree 2 Do not operate in environments where cond–
uctive pollutants m ay be present (as defined in IEC 61010-1). Rated
for indoor use only.
Safety Summary
Review the following safety precautions to avoid injury and prevent d amage to
this product or any products connected to it. To avoid potential hazards, use this
product only as specified. Using the probe or accessories in a manner not specified
couldresultinashockorfire hazard.
To Avoid Fire or Personal
Injury
Ground-Referenced Oscilloscope Use. Do not float the reference lead o f this probe
when using w ith ground referenced oscilloscopes (for example, TDS2000C series
oscilloscopes). The reference lead must be connected to earth potential (0 V).
TPS2000 and TPS2000B Series Oscilloscope Use. Do not float the reference lead
of this probe above the rated float voltage (30 V
RMS
).
Connect and Disconnect Properly. Connect the probe output to the measurement
instrument before connecting the probe to the circuit under test. Disconnect
the probe input and the probe reference lead from the circuit under test before
disconnecting the probe from the measurement instrument.
Avoid Electric Shock. Do not connect or disconnect probes or test leads while
they are connected to a voltage source.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Avoid Electric Shock. When using probe accessories, never exceed the lowest
rating of the probe or its accessory, whichever is less, including the measurement
category and voltage rating.
Inspect the Probe a nd Accessories. Before each use, inspect the probe and
accessories for damage (cuts, tears, defects in the probe body, accessories, cable
jacket, etc.). Do not use if damaged.
136 TPS2000B Series Digital Oscilloscope User Manual
