Reference
Video signal op
tions
Details
Odd Fields
Displays seve
ral fields and the oscilloscope triggers only on
odd numbered fields
Even Fields
Displays several fields and the oscilloscope triggers only on
even numbered fields
Undo Autoset
Causes the oscilloscope to recall the previous setup
NOTE. Video autoset sets the Display Type option to Dots mode.
Cursor
Push the Cursor button to display the measurement cursors and Cursor Menu,
and then use the multipurpose knob to change the position of a cursor.
Options Setting
s
Comment
s
Type
1
Time, A
mplitude, Off
Select
and display the measurement
cursors; Time measures time, frequency,
and amplitude; Amplitude measures
amplit
ude, such as current or voltage
Sourc
e
Chann
els1,2,3
2
,4
2
,
MATH, REFA, REFB,
REFC
2
,REFD
2
Choos
e the waveform on which to take the
cursor measurements
Cursor readouts display the measurement
Δ
Displays the absolute value of the
diff
erence (delta) between the cursors
Curs
or 1
Cur
sor 2
Disp
lays selected cursor location (time
is referenced to the trigger position, and
amplitude to the reference connection)
1
For a Math FFT source, measures Frequency and Magn itude.
2
Available only on a 4-channel oscilloscope.
100 TPS2000B Series Digital Oscilloscope User Manual
