Appendix A: TPS2000B Speciﬁcations

Table 8: Measur

ement Speciﬁcations

Characteristics Description

Cursors Amplitude difference between cursors (ΔV, ΔA, or ΔVA)

Time difference between cursors (Δt)

Reciprocal o

f ΔtinHertz(1/Δt)

Automatic Measurements

Frequency,

Period, Mean, P k-P k, Cycle RMS, M in, Max, Rise Time, Fall Time, Pos Width, Neg W idth

Table 9: Oscilloscope General Speciﬁcations

Characteristic Description

Display

Display Type

5.7 in. (145 mm) diagonal liquid crystal

Display Resolution 320 horizontal by 240 vertical pixels

Backlight Intensity, typical

60 to 100 cd/m

128 TPS2000B Series Digital Oscilloscope User Manual
