Operating Basics
Edge trigger for the rising edge.
Edge trigger for the falling edge.
Video trigger for line sync.
Video trigger for field sync.
Pulse Width t
rigger, positive polarity.
Pulse Width
trigger, negative polarity.
14. Readout shows Edge or Pulse Width trigger level.
15. Display area shows helpful messages; some messages display for only three
seconds.
If you recall a saved waveform, readout shows information about the reference
waveform, such as RefA 1.00V 500µs.
16. Readout shows date and time.
17. Readout shows trigger frequency.
18 TPS2000B Series Digital Oscilloscope User Manual
