TS4000 Radio Modem User’s Manual Serial Port 20
Selection Description
Available for
Configuration
This is a status box and cannot be set.
When this is checked it indicates the firmware is a
version (5.00 or higher) that supports the use of Serial
port 2 for configuration of the modem, control of the
modem operation and for diagnostics.
Available for Remote
Diagnostics
This is a status box and cannot be set.
When this is checked it indicates that the remote
diagnostics firmware option is enabled (see Remote
Diagnostics).
This function is an extra cost firmware option. Please
contact Teledesign for information on purchasing and
enabling this option.
This function also requires version 5.00 or higher
firmware.
Remote diagnostics also requires that AirNet packet
operation is enabled (see AirNet Packet Protocol).
Serial Port 2 Enable
The baud rate list provides selection of the serial port asynchronous baud rate.
The serial port 2 baud rate is fixed at 9600 baud.
Baud Rate List
The number of data bits for serial port 2 is fixed at eight.
Data Bits
The parity of serial port 2 is fixed at no parity.
Parity
No handshake line (RTS) is required for the incoming data.
Tx Data Protocol – Data
Activation
DCD is active when the TS4000 detects a signal on the radio channel. This
mode can be used to remote the receive light.
DCD Line Control – Active
when Radio Carrier
Detected
CTS is active when the TS4000 is transmitting. This selection can be used to
remote the transmit light.
CTS Line Control – Active
when Transmitting
DSR is active when the TS4000 is powered and there are no active faults. An
active fault is indicated by a flashing power light.
DSR Line Control – Active
when Operational
