Appendix D - Case Dimensions
3.10
"
0.56"
1.98"
0.56"
Standard Enclosure
4.25"
4.93"
1.14"
0.99" 0.99"
TS4000 Radio Modem
Serial Number: 012345
1.78
"
Optional
Mounting Plat
e
1.78
"
4-40 tapped
Mounting Hole,
6 places
1.14"
DATA PORT 1TX RX PWR PWR
DATA PORT 2
BNC RF
connector
standard
9-pin
female
D connectors
Molex
Micro-Fit 3.0
power
connector
