TS4000 Radio Modem User’s Manual Appendix D - Case Dimensions 88
3.10
"
0.56"
1.98"
0.56"
Water Tight Enclosure
4.25"
4.93"
1.14"
0.99" 0.99"
TS4000 Radio Modem
Serial Number: 012345
TX RX PWR
1.78
"
Optional
Mounting Plat
e
1.78
"
LEMO
Sealed
Connector
4-40 tapped
Mounting Hole,
6 places
DATA PORTS
Shown with
optional TNC
RF connector
1.14"
