TS4000 Radio Modem User’s Manual Appendix C - Specifications 83
Specifications:
TS4000-02A
Frequency Range 403-512 MHz
Radio - General
Frequency Bands 403-419 MHz, 419-435 MHz, 435-451 MHz, 450-470 MHz,
464-480 MHz, 480-496 MHz, 496-512 MHz
Channel Step Size 6.25, 10, 12.5 kHz
Frequency Stability +/- 1.5 ppm
FCC ID JWFTS4000A (403 - 512 MHz)
FCC Authorizations 11K2F1D, 16K0F1D, 20K0F1D
IC (Industry Canada) ID 3163195426 (403 - 512 MHz)
IC Authorizations 11K2F1D, 16K0F1D, 20K0F1D
Transmit Power 0.1 to 2 watts (programmable),
Radio - Transmitter
External amplifiers available for up to 100 watts
Duty Cycle 50% @ 2 watts, 90% @ 0.2 watts and below
Attack Time 19 ms
Receive Data Sensitivity/ -103 dBm for less than 1 x 10
-4
BER
Radio - Receiver
BER (Bit Error Rate)
Carrier Detect Threshold -110 to -60 dBm (programmable)
Receive Filter Bandwidth 12.5, 25 kHz
Selectivity -60 dB (12.5 kHz)
-70 dB (25 kHz)
Spurious/Image Rejection -70 dB
Intermodulation -70 dB
Supply Voltage 9 to 28 VDC (Full transmit power)
General
7 to 9 VDC (Reduced transmit power)
Power 1.0 watts - Standby (typical)
1.5 watts - Receive (typical)
7.0 watts - Transmit (typical)
Dimensions 4.3" x 3.1" x 1.8" (109 mm x 79 mm x 46 mm) w/o heat sink
Weight 14 ounces (400 grams)
