TS4000 Radio Modem User’s Manual Appendix C - Specifications 85
Specifications:
TS4000-05C
Frequency Range 132-174 MHz
Radio - General
Frequency Bands 132-150 MHz, 150-174 MHz
Channel Step Size 2.5, 5, 6.25, 7.5, 12.5 kHz
Frequency Stability +/- 2.5 ppm
FCC ID JWFTS4000C
FCC Authorizations 6K00F1D, 11K2F1D, 16K0F1D, 20K0F1D
IC (Industry Canada) ID 3163195539A
IC Authorizations 6K0F1D, 11K2F1D, 16K0F1D, 20K0F1D
Transmit Power 0.5 to 5 watts (programmable),
Radio - Transmitter
External amplifiers available for up to 100 watts
Duty Cycle 50% @ 5 watts, 90% @ 2 watts and below
Attack Time 19 ms
Receive Data Sensitivity/ -103 dBm for less than 1 x 10
-4
BER
Radio - Receiver
BER (Bit Error Rate)
Carrier Detect Threshold -110 to -60 dBm (programmable)
Receive Filter Bandwidth 15, 30 kHz
Selectivity -60 dB (15 kHz)
-70 dB (30 kHz)
Spurious/Image Rejection -70 dB
Intermodulation -70 dB
Supply Voltage 14 to 28 VDC (Full transmit power)
General
11 to 14 VDC (Reduced transmit power)
Power 1.0 watts - Standby (typical)
1.5 watts - Receive (typical)
24 watts - Transmit (typical)
Dimensions 6.5" x 3.1" x 1.8" (165 mm x 79 mm x 46 mm) with heat sink
Weight 20 ounces (60 grams)
