TS4000 Radio Modem User’s Manual Radio Setup 30
Selection Description
Transmit Data
Inversion
This controls the transmit data polarity in 3295 mode. This
control corresponds to the transmit polarity jumper on the
interface board.
Receive Data
Inversion
This controls the receive data polarity in 3295 mode. This
control corresponds to the receive polarity jumper on the
interface board.
Data Polarity
This should be set to match the type of Trimble data link that the TS4000 must
operate with.
Trimble Options - Mode
This should be set to match the channel spacing of the Trimble data link that the
TS4000 must operate with.
Trimble Options – Channel
Spacing
These controls enable store and forward repeater operation in Trimble
compatible mode.
Trimble Options – Store
and Forward Repeaters
