TSA-1000

– Page 14 of 14 –

7.6 Table of Technical Specifications, TSA-1000

ITEM RATING REMARKS COMMUNICATION

PARAMETERS

MECHANICAL

Dimensions (W / H / D)

370 / 290 / 90 mm

Weight (excluding batteries)

TSA-1000E4 or TSA-1000E8 3,470 gr.

TSA-1000Ex and TSA-1000EM083 3,600 gr

TSA-1000Ex and TSA-1000EM422 3,600 gr.

ENVIRONMENTAL

Operating Temperature range

-5°C ÷ +40°C, Max RH 95% Non condensing

IP rating

Environmental class A

POWER RATINGS

Mains Supply 230VAC+10% -15%, 50Hz , 0.6A TB line connection

Mains Supply Fuse 3.15A 250VAC 5x20mm glass Fast Blow Bussman S500-3.15-R or equiv.

Power Supply output rating, 27.5V±0.3V, 8 pin header

Total output current 1.5A electronic current limit (including charge current),

5V output rating 5V, ±0.2V 0.5A electronic current limit

Max Ripple Voltage 28V & Charger out: 320mV, 5V out: 80 mV
