TSA-1000

– Page 20 of 20 –

ITEM RATING REMARKS COMMUNICATION

PARAMETERS

TSA-1000C – Communication

Module

RS-232 1

RS-485 2

FWRE 1

For PC connection

Remote panels and networking

Fault dialer

RS-232

RS485

Modulated DC

GENERAL

Input nominal quiescent voltage,

current

18.5v, 5.0mA Current Limit

Terminal block wire capacity 12-18 AWG

Max number of detectors per zone 32

Number of detection zones Dependant on HW configuration

Total number of detectors Dependant on HW configuration

CABLING SEE "INSTALLATION"

Table 1 Technical Specifications

Note

Specifications are subject to change without prior notice.
