To Next PageTo Next PageWhat does ' empty extinguishing container' mean on Telefire GUARD-7 Control Panel?
If the Telefire Control Panel displays ' empty extinguishing container', it means the empty extinguishing container is disconnected at the extinguishing controller. Reconnect it.
How to enable a disabled device on Telefire GUARD-7?
If your Telefire Control Panel shows 'Disabled,' it indicates that a device or area has been disabled. To enable it: - Open the start/stop device menu from the main menu. - Select the device or area indicated in the message. - Click 'Enable'.
What does 'Main circuit disconnect' mean on my Telefire Control Panel?
If the Telefire Control Panel shows 'Main circuit disconnect' for a specific device, it means that the designated device is disconnected. Check the line continuity and connect an end of line resistor (5.1K?) at the output circuit connectors.
How to fix 'Main circuit short' on a Telefire GUARD-7?
If the Telefire Control Panel displays 'Main circuit short' for a device, it indicates a short circuit on that device. Find the cause of the short circuit and remove it.
What causes 'Main circuit low voltage' on Telefire GUARD-7?
If the Telefire Control Panel displays 'Main circuit low voltage' for a specific device, it means the voltage is low on that device. If the device is the battery or backup battery (3V), replace the battery or backup battery (R2032C). Otherwise, the control panel may be faulty and should be sent to the manufacturer for repairs.
Why does my Telefire GUARD-7 show 'Main circuit limited current'?
If the Telefire Control Panel displays 'Main circuit limited current' for a device, it means that the current has been limited on the designated device. Locate the source of the fault, such as damaged wire or a water leak, and repair it.
What does 'Main circuit exists, not programmed' mean on Telefire GUARD-7 Control Panel?
If your Telefire Control Panel displays 'Main circuit exists, not programmed' for a device, it means the device is present in the system but hasn't been defined yet. Define the device to resolve this.
Why does my Telefire GUARD-7 Control Panel show ' extinguishing circuit is disconnected'?
If the Telefire Control Panel displays ' extinguishing circuit is disconnected', it indicates that the extinguishing circuit is disconnected at the extinguishing controller. Reconnect the circuit.
What to do if Telefire Control Panel says ' abort extinguishing is disconnected'?
If the Telefire Control Panel displays ' abort extinguishing is disconnected', it means the abort extinguishing is disconnected at the extinguishing controller. Reconnect it.
What does ' disconnect on manual override' mean on Telefire GUARD-7 Control Panel?
If the Telefire Control Panel displays ' disconnect on manual override', it means the manual override is disconnected at the extinguishing controller. Reconnect it.
Details the primary control board of the ADR-7000 system.
Explains user access control and different security levels.
Details system behavior during an alarm event.
Explains system behavior when a fault occurs.
Details the mode for system testing without activating outputs.
Planning of quantity and location of devices and system layout.
Steps for installing various system devices and modules.
Configures outputs for automatic extinguishing systems.
Procedures for manually activating extinguishing systems.
Details the function and installation of extinguishing disconnect switches.
Steps to access the system configuration mode.
Procedure for testing all initiating devices in the system.
Lists and explains error messages displayed by the control panel.
Identifies common system faults and their causes/repairs.
Troubleshooting specific faults related to addressable devices.
Lists and explains faults encountered during system programming.
General warnings about system assembly, configuration, and installation.
Details the system's power supply capabilities and battery requirements.
Final calculation of battery requirement and system load.
Confirms UL 864 compliance for the ADR-7000 system.
Outlines compliance with EN 12094-1 for extinguishing systems.
General| Zones | 7 |
|---|---|
| Input Voltage | 230VAC |
| Operating Temperature | -10°C to +55°C |
| Enclosure Protection | IP30 |
| Sounder circuits | 1 |
| Battery | 12V/7Ah |
| Weight | 2.5 kg |
| Compatibility | Conventional detectors |
