LED
Meaning
Aux 24V Fault
Yellow LED. Indicates a fault in the auxiliary 24Vdc outputs.
Additional detail is shown on the LCD display.
 Off during normal operation
 Flashes on upon a fault event in any output device (other
than Horn and outputs configured as "General, Silenced").
Pressing Acknowledge will turn the LED solid on until
resolution of the problem
Outputs Delayed
Yellow LED. Indicates that an output is delayed and will be
activated once the countdown period is over.
 Off during normal operation
 On during the countdown process
Abort
Yellow LED. Indicates an aborted extinguishing operation. Off
during normal operation
 Off during normal operation
 On following an abort
A
Reserved for future use
Fire
Red LED. Indicates fire alarm. The device in alarm is displayed
on the LCD display.
 Off in normal state
 Flashes during alarm. Pressing the Acknowledge key will
turn the LED on until the control panel is reset
Supervisory
Yellow LED. Indicates a supervisory event.
 Off during normal operation
 The LED flashes as long as the supervisory event is in
force.
Alarm Verify
Yellow LED. Indicates alarm verification. Also displayed on the
LCD display.
 Off in normal operation
 Flashes during alarm verification
Disabled
Yellow LED. Indicates a disabled input, or output. Additional
detail is shown on the LCD display.
 Off during normal operation
 On when one of the inputs or outputs is disabled.
Additional detail is shown on the LCD display. The LED will
stay on until all inputs, and outputs are enabled.
