ADR-7000 / SAVER-7000 / GUARD-7
© 2017 – Telefire Fire & Gas Detectors Ltd Revision 0.98 October 2017
– Page 37 of 87 –
Pressing this key silences only internal buzzer.
In normal mode – used to scan through the existing events.
The top row of the LCD will show the recalled event number
and description. The total number of events will be
displayed on the lower right.
In program mode – moves the address to the next active
device.
Pressing this key silences the devices connected to the General
Alarm NAC (if defined as Silenced), HORN output, and all
addressable outputs that are defined as "silenced".
Pressing this key resets and restores the system to normal
operation mode. All NACs are turned off, input and output
modules return to normal operation mode, addressable
detectors receive a reset signal, the LCD displays "System OK"
and history report is updated. The system will resound if any
Alarm or Trouble occurs.
Table 2 Operator Panel – Operator Keys
6.4 Numerical and Arrow Keys
6.4.1 Numerical Keys
The numeric keys are used for entering values for system initialization, programming,
daily operation, password entering, and selecting menu field values on the LCD.
6.4.2 Arrow Keys
The arrow keys are used for navigating from field to field on the screen during system
programming and for browsing through the memory.
