 Device Type: the device type as follows:
 Photoelectric Detector: (TFO-480A or TFO-440A)
 Heat Detector: (TFH-280A or TFH-220A). Detector mode (Fixed Temperature
(default) or Rate of Rise) is defined in the Mode field.
 Gas Detector: reserved for future use
 Input Module (ADR-712; ADR-718; ADR-812A or ADR-818A). Mode can be
Alarm; Reset; Silence; Disconnect; Supervisory; Abort; Release; Alarm Matrix;
or Fan PC).
 Switch: (a manual call point (TPB-800ASR, TPB-800ASY, or TPB-101ASM),
an input of an ADR-805A or ADR-705; or the IDC input or an ADR-723 or
ADR-823A). Switch operating mode is defined in the Mode field, and can be
Alarm; Reset; Silence; Disconnect; Supervisory; Abort; Release; Alarm Matrix;
or Fan PC.
 Power supply: an auxiliary power supply (TPS-34A)
 Sounder (TIP-224A, or an ADR-723 or ADR-823A output that activates
sounders). Operation mode is defined in the Mode field and can be No
Protocol or with the Control Panel's protocol.
 Lamp: an ADR-723 or ADR-823A output that activates a strobe
 Extinguisher: an ADR-723 output that is used to release extinguishant. The
Mode field specifies pulse length (5 seconds to 239 minutes, or continuous until
reset). Default is 15 seconds.
 Extinguisher Control: (ADR-833A).
 Control Out: the output of an ADR-723 or ADR-823A; or the relay of an
ADR-723, ADR-823A, or an ADR-741). The Mode field defines whether it is
activated by an alarm or a fault.
 Isolator: an addressable line isolation module (LI-3000)
 CO & Heat Detector: reserved for future use
 Photo & Heat Detector: (TPH-482A or TPH-442A)
 Supervisory Out: the output of an ADR-723 or ADR-823A; or the relay of an
ADR-723, ADR-823A, or an ADR-741 that is activated as a result of a
Supervisory event.
i
Note
A supervisory input or switch and its related supervisory out should be in the
same logical zone.
 Fire Phone Jack: (TFP-806)
 Fire Phone Lamp: (and address of a TFP-828)
 SCM: the relay of an ADR-723, or an ADR-741 that is intended to activate or
stop a smoke control blower.
 Zone: the device's logical zone. Can be in the range of 1 – 511.
 Mode: the device's operating mode, device dependent.
 For heat detectors: fixed temperature or rate of rise
 For Input module: Alarm; Reset; Silence; Disconnect; Supervisory; Abort;
Release; Alarm Matrix; or Fan PC
