ADR-7000 / SAVER-7000 / GUARD-7
© 2017 – Telefire Fire & Gas Detectors Ltd Revision 0.98 October 2017
– Page 81 of 87 –
Appendix A – Current Consumption and Battery Capacity
Calculation
Repeat this process separately for each control panel.
Fill in the following table to calculate the total load on the system’s power supply during
quiescence (standby) state and alarm.
Quiescence
Alarm
Device
QTY
Current
Total
Current
Total
Internal modules and
NACs
ADR-7000/1
(single loop)
{ } X
76.00 mA
=
280.0 mA
=
Additional loops
{ } X
17.00 mA
=
17.0 mA
=
LON-7000
{ } X
10.00 mA
=
10.0 mA
=
NET-7000
{ } X
120.00 mA
=
120.0 mA
=
GIM-232
{ } X
1.50 mA
=
1.5 mA
=
TDM-500i
{ } X
20.00 mA
=
300.0 mA
=
TIP-224
{ } X
0 mA
= 0
40.0 mA
=
Other NAC
{ } X
mA
=
mA
=
Other NAC
{ } X
mA
=
mA
=
Other NAC
{ } X
mA
=
mA
=
Current to loops
TFO-480A / 440A
{ } X
0.29 mA
=
2.6 mA
=
TFH-280A / 220A
{ } X
0.20 mA
=
2.6 mA
=
TPH-482A / 442A
{ } X
0.29 mA
=
2.6 mA
=
TFL-1AN
{ } X
0 mA
= 0
10.0 mA
=
TPB-800ASR
{ } X
0.12 mA
=
2.0 mA
=
TPB-800ASY
{ } X
0.12 mA
=
2.0 mA
=
LI-3000C
{ } X
2.20 mA
=
4.0 mA
=
LI-3000E
{ } X
0.5 mA
=
4.0 mA
=
ADR-712
{ } X
0.3 mA
=
15.0 mA
=
ADR-718
{ } X
0.3 mA
=
15.0 mA
=
ADR-723
{ } X
0.2 mA
=
2.8 mA
=
ADR-741
{ } X
0.3 mA
=
3.2 mA
=
ADR-805A Rev B
{ } X
0.26 mA
=
3.0 mA
=
ADR-805A Rev C
{ } X
0.20 mA
=
2.0 mA
=
ADR-812A
{ } X
0.15 mA
=
2.1 mA
=
ADR-818A
{ } X
0.26 mA
=
2.1 mA
=
ADR-823A
{ } X
0.30 mA
=
2.8 mA
=
ADR-828A
{ } X
0.39 mA
=
3.0 mA
=
ADR-833A
{ } X
6.50 mA
=
6.5 mA
=
TIP-224A
{ } X
0.12 mA
=
5.0 mA
=
TPS-34A
{ } X
0.34 mA
=
0.5 mA
=
TFP-3000
{ } X
15.00 mA
=
70.0 mA
=
TFP-1CP
{ } X
0.25 mA
=
2.8 mA
=
TFP-806
{ } X
0.25 mA
=
2.8 mA
=
TFP-828
{ } X
0.39 mA
=
3.0 mA
=
Totals
(a)
=
(b)
=
Table 3 Power Requirement – Internal and SLC
