LED Its Color and meaning
(EN 54 / CP 10 version)
Its Color and meaning (UL 864
/ IS 1220 version)
Alarm
Red LED. Indicates fire alarm.
The zone in alarm is displayed
on the digital display and is
indicated by the zone’s private
indication LED.
• Off in normal state
• Flashes during alarm until
the control panel is reset
Red LED. Indicates fire alarm.
The zone in alarm is displayed
on the digital display and is
indicated by the zone’s private
indication LED.
• Off in normal state
• Flashes during alarm.
Pressing the Acknowledge
key will turn the LED on
until the control panel is
reset
AVF
Yellow LED. Indicates alarm
verification. AVF is also
displayed (V##) on the digital
display.
• Off in normal operation
• Flashes during alarm
verification
Yellow LED. Indicates alarm
verification. AVF is also
displayed on the digital display.
• Off in normal operation
• Flashes during alarm
verification
Supervisory
Yellow LED. Indicates a
supervisory event.
• Off during normal operation
• The LED flashes as long as
the supervisory event is in
force. Additionally the
zones supervisory LED also
flashes
Yellow LED. Indicates a
supervisory event.
• Off during normal operation
• The LED flashes as long as
the supervisory event is in
force. Additionally the
zones supervisory LED also
flashes
Disabled
Yellow LED. Indicates a
disabled input or output.
Additional detail is shown on the
digital display.
• Off during normal operation
• On when one of the inputs
or outputs is disabled.
Additional detail is shown
on the digital display. The
LED will stay on until all
inputs and outputs are
enabled.
Yellow LED. Indicates a
disabled input, or output.
Additional detail is shown on the
digital display.
• Off during normal operation
• On when one of the inputs
or outputs is disabled.
Additional detail is shown
on the digital display. The
LED will stay on until all
inputs, and outputs are
enabled.
