MCC201/MCC201H User manual
1. Introduction
About this manual
This User Manual provides information on installation setup and operation of the MCC201 and MCC201H,
as well as troubleshooting tips.
Features
MCC201 is a video and audio transmission system that provides broadcast quality audio and video, based on
IP networking. MCC201 can operate either as an Encoder or as a Decoder, the desired mode is user-
selectable. MCC201H is a model variant which has all other functions available except HD-SDI operation.
Video
Highly efficient compression algorithm, H.264 (Baseline and High profiles) & MJPEG support
Wide range of transmission rates: Primary stream 32 kbps...10 Mbps, secondary stream max. 1 Mbps
Various transmission modes: CBR, VBR
Motion detection
Support for analogue baseband video, HDMI video and HD-SDI video
(Note! HD-SDI video not available on MCC201H)
Audio
Multi-Transmission Mode : Unidirectional Mode (IP-server to Client PC or Decoder / Client PC or
Decoder to IP-server), Bi-directional Mode
Network
Fixed IP & Dynamic IP (DHCP) support
1:1, 1:N support
Multicasting
Automatic transmit rate control according to network conditions
OnVIF, PSIA compliant
Serial Data
RS-232 support
RS-422 (4-w) or RS-485 (2-w) support
Data pass-through mode : Serial data communication between Encoder - Decoder
