BurnIn OSD
Insert text for System ID and enable timestamp (date & time) for the streamed video. The information is added
on top of video before encoding. System ID and time respectively can be turned on or off in the video. Position
and Font size can be configured also. System ID for BurnIn OSD exists independently from normal System ID.
Note! That size of Burnin OSD display varies according to the encoding resolution setting. This is inevitable
because Burnin OSD is inserted to the frames before encoding is performed. The following table describes the
rule for BurnIn OSD display.
Resolution Small (8x8) Middle (16x16) Large (32x32)
352x480 / 352x240 / 352x576 / 352x288 2 1 0
720x480 / 720x240 / 720x576 / 720x288 /
640x480 / 800x600
2 2 1
1024 x 768 / 1280x720 / 1280 x 960 / 1280x1024 /
1440x900 / 1600x900 / 1680x1050 / 1920x1056 /
1920x1080 / 2048x1536 / 2560x1600 / 2592x1936
2 2 2
2 : Both System ID and Time are displayed.
1 : Either System ID or Time can be displayed. When both are enabled, System ID is displayed.
0 : No items are displayed. This is because video area is too small to display OSD text in large text.
Output Format
When in encoder mode the input video signal is available for local monitoring and previewing either on
the composite video output (BNC out) or on the digital output (HDMI out).
Note! The preview video is captured before entering the encoding engine of the device.
Select the output format for the monitor preview according to the video output and monitor specification.
The available preview modes are:
• NTSC (720 x 480)
• PAL (720 x 576)
• 720p60 (1280 x 720)
• 1080i60 (1920 x 1080)
• 720p50 (1280 x 720)
• 1080i50 (1920 x 1080)
• 1080i59.94 (1920 x 1080)
• 720p59.94 (1280 x 720)
• 1080p30 (1920 x 1080)
