MCC201/MCC201H User manual
4. Remote Configuration • 35
Serial Port Configuration
Serial Protocol: Two COM ports are available at MCC201 and MCC201H; RS-232 and RS-422/485.
See more information in appendix 6 (e.g. wiring details).
Serial Port Configuration: The serial ports can be configured as follows.
Note! Each of the serial ports configurations must be same as the connecting device.
PTZ
PTZ Type: Select the type of PTZ camera or receiver.
PTZ ID: Since it is possible to control multiple PTZ cameras or receivers over single control line,
each camera or receiver will be assigned with unique ID. Enter PTZ ID of a camera or receiver for control.
The ID value range can be between 0 and 255.
PTZ Port: Select the serial port used for PTZ camera control.
Sensor Type
There are two sensor input ports on MCC201. Each of the sensor ports can be configured to the following.
The function of the sensor port is set based on the type of the sensor connected.
Mode Selection
Bitrate 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Data Bits 5, 6, 7, 8 bits
Parity NONE, EVEN, ODD bit
Stop Bit 1, 2 bit
Function Operation
OFF Not used.
NO (Normally Open) The port is normally open and activated when closed.
NC (Normally Closed) The port is normally closed and activated when opened.
