36 en | Assembly AIRMAN 8+
2024-11 | 07 | F.01U.387.060
Customer Maintenance Manual
Bosch Security Systems, LLC
Models -0210, -0211, -0212 Model -0214
13. Using a T-5 screwdriver, replace the three screws (as shown) to attach the yoke and
housing to the PCBA.
Models -0210, -0211, -0212 Model -0214
1. Position the overhead cord in the guide, and then align the knob of the faceplate
toward the bottom.
2. Align the four tabs on the faceplate, and then rotate counterclockwise to lock.
i
Notice!
Verify all four tabs engage and retaining tabs are in the groove.
