Telex AIRMAN 8+ - Non-Boom Side Disassembly

AIRMAN 8+ Disassembly | en 31
Bosch Security Systems, LLC
Customer Maintenance Manual
2024-11 | 07 | F.01U.387.060
i
Notice!
Take care to avoid touching the plastic housing with the soldering iron.
6.6 Non-boom side disassembly
To remove the speaker assembly and sleeve, do the following:
1. Pushing the two retaining cams simultaneously on the speaker assembly, rotate the
speaker faceplate approximately 15° clockwise.
i
Notice!
To avoid pulling the wires from the board, do not pull the speaker assembly more than
12mm from the ear shell.
2. Using a T-5 screwdriver, remove three screws (as shown).
