AIRMAN 8+ Wiring Diagrams and Connectors | en 45
Bosch Security Systems, LLC
Customer Maintenance Manual
2024-11 | 07 | F.01U.387.060
J14
J13
SPEAKER
NON-BOOM SIDE
SPEAKER
BOOM SIDE
SHIELD
DRAIN WIRE
WIRING DIAGRAM F01U425841
CABLE ITEM 48 WIRING, XLR
J5 - YELLOW
J6 - BLACK
J2 - BLUE AND DRAIN WIRE
J1 - WHITE
J15 - RED
TRIM SHIELD FLUSH WITH JACKET
PCBA F01U414950 ITEM 49
NON-BOOM SIDE, BOTTOM
J13
J14
J8
J7
J18
J5 J6 J2 J1 J15
J11
J12
J9
J10
J17
J18
J8
J7
J5 J6 J15J2 J1
J11
J12
J9
J10
J17
PCBA F01U414950 ITEM 49
NON-BOOM SIDE, TOP
BLACK
WHITE
BLUE
RED
PCBA F01U414952 ITEM 50,
BOOM SIDE, TOP
WHITE
RED
YELLOW
BLUE
PCBA F01U414952 ITEM 50
BOOM SIDE, BOTTOM
BLACK
USE THE SHIELD OF THE
MICROPHONE
CABLE AS AN ANCHOR POINT.
CUT AMBER WIRE OFF FLUSH.
POLARITY DOT
RED
WHITE
POLARITY DOT
RED
WHITE
+
GREEN
RED
CUT SHIELD AND AMBER
OFF FLUSH WITH JACKET
THIS END ONLY.
Figure8.6: Airman8P-0214 Wiring Diagram
