LN930 M.2 Hardware User Guide
1VV0301078 Rev.10 – 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 11 of 88
This document is a technical specification for Telit’s next generation form factor M.2 module
family. The next generation form factor M.2 module family is a natural transition from the
PCI Express Mini Card and Half Mini Card to a smaller form factor size.
The M.2 Card Type 3042 offers single sided component mounting, 75 pins (8 dedicated for
key), in a compact size (30 mm x 42 mm). A range of 2G/3G/4G (LTE) M.2 modules
supporting multiple operating systems and unique features in the WWAN Card Type 3042
form factor are available.
The document will cover the features of the M.2 modules presently available. It will also
identify the M.2 module application interface along with hardware, software, reliability, and
mechanical specifications.
The intent of this document is to provide design guidelines and information for each M.2
module.
In addition to the M.2 module family features and performance metrics, this document
describes the interface signals, operating conditions, physical and mechanical requirements of
the M.2 cards.
This document is intended for editors who are about to write or edit documentation for Telit.
Contact Information, Support
For general contact, technical support, to report documentation errors and to order manuals,
contact Telit Technical Support Center (TTSC) at:
TS-EMEA@telit.com
TS-NORTHAMERICA@telit.com
TS-LATINAMERICA@telit.com
TS-APAC@telit.com
Alternatively, use:
http://www.telit.com/en/products/technical-support-center/contact.php
For detailed information about where you can buy the Telit modules or for recommendations
on accessories and components visit:
