• Correction in Section 11.3, fixed typo in sentence: For WWAN M.2
Modules, only positions 1 and 4 are used.
• Updated table to only indicate minimum RX sensitivity limit.
• Updated Section Conducted Transmit Power section.
• Added CAT 4: DL 150 Mbps, UL 50 Mbps to APAC LTE in Table 3
• Deleted LED Blink Status in Table 14
• Updated Table 4 and Table 27
• Added Humidity Requirement
• Removed Quality & Reliability section since this is a requirement of the
ODM.
• Correction to: DPR signal includes pull-up, SSIC N/P pin locations, COEX
pin names.
8
2014-06-24
• Added IC Canada certification wording.
• Section 3.2.1, SIM Design Recommendations - added new section
• Section 3.12, Antenna Interface changed connector of the WWAN antenna
cable to iPEX MHF4 from Hirose W.FLT
• Section 7, Table 24. Operating Environment changed description for
Operating Temperature to include extreme temperature +55 °C to +70 °C
and added additional description
• Section 8.2, deleted Table 27. Electrical Parameters – Host Interface
Signals and replaced it with:
o Table 27. DC Specification for 3.3 V Logic Signaling
o Table 28. DC Specification for 1.8 V Logic Signaling
• Section 8.3, Table 29. LTE Power Consumption
o Added additional LTE Use Cases for APAC SKU only - Bands
1, 3, 8, 9, 11, 18, 19, and 21
o Changed standby power to 8 mW
• Section 9.6, -
o Table 35. Rx Sensitivity – GSM - added note indicating that
GSM is not supported for APAC SKU.
o Table 36. Rx Sensitivity – UMTS– added note indicating that
the minimum limits reflects that the main and diversity ports are
combined.
o Table 37. Rx Sensitivity – LTE – added note indicating that the
8 LTE bands 2, 4, 5, 7, 13, 17, 20, and 26 is not supported for
APAC SKU
• Section 9.7, Antenna Recommendations
• Table 38. Antenna Recommendation, added note indicating that the
first 2 recommendations for Input Power are not supported for APAC
SKU.
• Table 39. Antenna Recommendation - Bandwidth of Main &
Diversity Antenna - added not indicating that the following 9 RF
Bands 007, 010, 013, 017, 020, 025, 026, 027, and 028 are not
supported by the APAC SKU.
9
2014-11-18
• Replaced Requirement with Target in Table 32 to Table 37.
• Changes to Table 32. Conducted Transmit Power – 2G
• Changes to Table 33. Conducted Transmit Power – 3G
• Changes to Table 34. Conducted Transmit Power – LTE
• Changes to Table 35. Rx Sensitivity – GSM
• Changes to Table 36. Rx Sensitivity – UMTS
• Changes to Table 37. Rx Sensitivity – LTE
•
Changes to Table 38. Antenna Recommendation
10
2014-12-21
• Added note to Table 3. WWAN M.2 Module – Data Services
• − The change is to describe we can support DL 150 Mbps in WW LTE
SKU. This is only for generic SW and VZW SW, but not for AT&T SW.
• Changes to Section 3.2 USIM Interface
• − Bullet number 2 and 3
• Changes to Section 3.2 USIM Interface
List number 2 and 3
• Changes to Table 4. WWAN M.2 Host Interface Signals pins 29, 31, 35,
and 37.
• Changes to Table 6. USB SSIC - ICP Interface
• Changes to Table 33. Conducted Transmit Power – LTE
• Changes to Table 4. WWAN M.2 Host Interface Signals pins 29, 31, 35,
37, and 67.
•
Changes to Table 36. Rx Sensitivity – LTE
