Telit Wireless Solutions LN930 - Table 1 M.2 Module - General Feature

LN930 M.2 Hardware User Guide
1VV0301078 Rev.10 – 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 14 of 88
Table 1 M.2 Module - General Feature
Feature
Description
Additional Information
M.2 module
HN930
LN930-AP
LN930
Mechanical
M.2 Card Type 3042
Slot B
30 mm x 42 mm
Pin count: 75
(67 usable, 8 slot)
x x x
Operating
Voltage
3.3 V +/- 5%
-
x x x
Operating
Temperature
-10˚C to +55˚C – Normal
+55˚C to +70˚C –
Extended
E
xtreme - This is the
surrounding air temperature of
the module inside the platform
when the card is fully operating
at worst case condition
x x x
Application
Interface
(75 pin card)
Interprocessor
Communications
USB 2.0 High-speed
x x x
USIM w/ Card Detect
SIM_CLK, SIM_RESET,
SIM_IO, SIM_PWR,
SIM_DETECT
x x x
M.2 Control
Full_Card_Power_On_Off
x x x
Reset#
x x x
W_DISABLE#
x x x
LED #1
x
x
x
DPR (Body SAR)
x x x
Wake on WWAN
x x x
GNSS Disable
x x x
Global Positioning
(GPS/ GLONASS)
I2C_SCL, I2C_SDA, I2_IRQ,
CLKOUT, TX_BLANKING
x x x
Antenna Tuning
(4) GPO (RF Transceiver)
- x x
RF Coexistence
(3) GPIO
- x x
RF Antenna
Main & Diversity/ GNSS
Separate coax connectors
x x x
Debug
JTAG
-
x x x
ETM11
-
- x x
MIPI PTI
-
- x X
