1VV0301078 Rev.10 ā 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 69 of 88
Table 36 Rx Sensitivity - UMTS
HDPA+ / LTE LN930
Band Condition Min Rx Sensitivity Limit (dBm)
1 BER<0.1% -107
2 BER<0.1% -106
4 BER<0.1% -107
5 BER<0.1%
-107
8 BER<0.1% -107
LN930-AP (APAC SKU only)
Band Condition Min Rx Sensitivity Limit (dBm)
1 BER<0.1% -106
6 BER<0.1% -106
8 BER<0.1% -103
11 BER<0.1%
-106
19 BER<0.1% -106
GSM not supported for LN930-AP
Main and Diversity ports are measured separately. Combining both antenna ports
increases sensitivity by 3 dB. Table 36 Rx Sensitivity ā UMTS reflects both ports
combined.
Table 37 Rx Sensitivity - LTE
HDPA+ / LTE LN930
EARFCN
LTE
Band
Duplex Modulation Bandwidth
(Hz)
Min Rx
Sensitivit
y Limit
(dBm)
Low
Channel
Middle
Channel
High Channel
