Intel Mobile Communications provides a carrier development board to facilitate system test
and verification of the M.2 module. In addition, a set of comprehensive tools to enable rapid
integration and customization of the M.2 software is provided.
The hardware and software tools for M.2 development are summarized below.
The M.2 Carrier Board, shown in Figure 11, is Intel Mobile Communications hardware
platform to facilitate the test and verification on the M.2 module. Once the M.2 module is
mounted on the Carrier board, the user has access to all necessary interfaces on the module
(host interface signals, debug and trace, and antenna) allowing full system test, debugging,
and diagnostics. The carrier board with a mounted WWAN M.2 module is shown in Figure
11. Carrier Board.
Note: The Main and Diversity antenna locations have been swapped on the FIH7160
PR3.2 and earlier modules.
