8.3
Power Consumption
This section lists the power consumption targets.
Typical target values at Vsys = 3.3 V
Table 29
LTE Power Consumption
M.2 Power Consumption (*)
Transmit Power
LTE Use Case
Band
10 dBm
23 dBm
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only)
1
1195 mW
2195 mW
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only)
3
1175 mW
2356 mW
LTE UTP, Cat. 3, 10 MHz, 50 RB - (APAC SKU only)
8
1000 mW
2201 mW
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only)
9
1175 mW
2244 mW
LTE UTP, Cat. 3, 10 MHz, 50 RB - (APAC SKU only)
11
1073 mW
2155 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only)
18
1122 mW
1911 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only)
19
1112 mw
1874 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only)
21
1208 mW
2270 mW
LTE UTP, Cat. 3, 100 Mbps/50 Mbps, 20 MHz – (APAC
not included)
7
1068 mW
2531 mW
LTE UTP, Cat. 3, max throughput, 10 MHz – (APAC not
included)
17
916 mW
2394 mW
LTE Use Case
Standby Power
LTE Stand-by current, DRX 1.28 s serv. Cell only 8 mW
(*) Applicable to modules:
• LN930
• LN930-AP
Table 30
UMTS Power Consumption
M.2 Power Consumption
Transmit Power
UMTS Use Case
(DC-HSDAP+ or HSDPA+)
Band
10 dBm
UMTS FTP, Cat. 24, RxDiv
(M.2 DC-HSDPA+)
Band 1 988 mW
