69
CONFIG_1 O Configuration Status
WWAN M.2 Connects to GND
internally
-
70
3.3V
P
WWAN Supply Pin 3.3 V
-
71
GND
P
Ground
-
72
3.3V
P
WWAN Supply Pin 3.3 V
-
73
GND
P
Ground
-
74
3.3V
P
WWAN Supply Pin 3.3 V
-
75
CONFIG_2 O Configuration Status
WWAN M.2 Connects to GND
internally
-
