Telit Wireless Solutions UE910 series User Manual

Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 12 of 93
B3
EAR-
O
Analog Audio Interface (EAR-)
Not available on UE910-
xxD/UE910-GL
B4
MIC+
I
Analog Audio Interface (MIC+)
Not available on UE910-
xxD/UE910-GL
B5
MIC-
I
Analog Audio Interface (MIC-)
Not available on UE910-
xxD/UE910-GL
Digital Voice Interface (DVI)
B9
DVI_WA0
I/O
Digital Audio Interface (WA0)
CMOS 1.8V
B6
DVI_RX
I/O
Digital Audio Interface (RX)
CMOS 1.8V
B7
DVI_TX
I/O
Digital Audio Interface (TX)
CMOS 1.8V
B8
DVI_CLK
I/O
Digital Audio Interface (CLK)
CMOS 1.8V
SPI
D15
SPI_MOSI
I
SPI MOSI
CMOS 1.8V
Shared with TX_AUX
E15
SPI_MISO
O
SPI_MISO
CMOS 1.8V
Shared with RX_AUX
F15
SPI_CLK
I
SPI Clock
CMOS 1.8V
H15
SPI_MRDY
I
SPI_MRDY
CMOS 1.8V
J15
SPI_SRDY
O
SPI_SRDY
CMOS 1.8V
DIGITAL IO
C8
GPIO_01
I/O
GPIO_01 /STAT LED
CMOS 1.8V
Alternate Function STAT LED
C9
GPIO_02
I/O
GPIO_02
CMOS 1.8V
C10
GPIO_03
I/O
GPIO_03
CMOS 1.8V
C11
GPIO_04
I/O
GPIO_04
CMOS 1.8V
B14
GPIO_05
I/O
GPIO_05
CMOS 1.8V
C12
GPIO_06
I/O
GPIO_06
CMOS 1.8V
C13
GPIO_07
I/O
GPIO_07
CMOS 1.8V
K15
GPIO_08
I/O
GPIO_08
CMOS 1.8V
L15
GPIO_09
I/O
GPIO_09
CMOS 1.8V
G15
GPIO_10
I/O
GPIO_10
CMOS 1.8V
ADC
B1
ADC_IN1
AI
Analog / Digital converter input
A/D
Accepted values 0 to 1.2V DC
RF SECTION
K1
ANTENNA
I/O
GSM/EDGE/UMTS Antenna
(50 ohm)
RF
Miscellaneous Functions
R13
HW_SHUTDOWN*
I
HW Unconditional Shutdown
CMOS 1.8V
Active low
R12
ON_OFF*
I
Input command for power ON
CMOS 1.8V
Active low
C14
VRTC
I
VRTC Backup capacitor
Power
backup for the embedded RTC
supply
R11
VAUX/PWRMON
O
Supply Output for external
accessories / Power ON Monitor
1.8V
Power Supply
M1
VBATT
-
Main power supply (Baseband)
Power
M2
VBATT
-
Main power supply (Baseband)
Power
N1
VBATT_PA
-
Main power supply (Radio PA)
Power
DRAFT
