3 UE910 module connections
3.1 PIN-OUT
PAD
Signal
I/O
Function
Type
COMMENT
USB HS 2.0 COMMUNICATION PORT
B15
USB_D+
I/O
USB differential Data (+)
C15
USB_D-
I/O
USB differential Data (-)
A13
VUSB
I
Power sense for the internal USB
transceiver.
Asynchronous Serial Port (USIF0) - Prog. / Data + HW Flow Control
N15
C103/TXD
I
Serial data input from DTE
CMOS 1.8V
M15
C104/RXD
O
Serial data output to DTE
CMOS 1.8V
M14
C108/DTR
I
Input for (DTR) from DTE
CMOS 1.8V
L14
C105/RTS
I
Input for Request to send signal
(RTS) from DTE
CMOS 1.8V
P15
C106/CTS
O
Output for Clear to Send signal
(CTS) to DTE
CMOS 1.8V
N14
C109/DCD
O
Output for (DCD) to DTE
CMOS 1.8V
P14
C107/DSR
O
Output for (DSR) to DTE
CMOS 1.8V
R14
C125/RING
O
Output for Ring (RI) to DTE
CMOS 1.8V
Asynchronous Auxiliary Serial Port (USIF1)
D15
TX_AUX
O
Auxiliary UART (TX Data to DTE)
CMOS 1.8V
E15
RX_AUX
I
Auxiliary UART (RX Data from
DTE)
CMOS 1.8V
USB HSIC
A12
HSIC_USB_DATA
I/O
USB HSIC data signal
CMOS 1.2V
A11
HSIC_USB_STRB
I/O
USB HSIC strobe signal
CMOS 1.2V
H15
HSIC_SLAVE_WAKEUP
I
Slave Wake Up
CMOS 1.8V
Shared with SPI_MRDY
F15
HSIC_HOST_WAKEUP
O
Host Wake Up
CMOS 1.8V
Shared with SPI CLK
K15
HSIC_SUSPEND_REQUEST
O
Slave Suspend Request
CMOS 1.8V
Shared with GPIO08
J15
HSIC_HOST_ACTIVE
I
Active Host Indication
CMOS 1.8V
Shared with SPI_SRDY
SIM card interface
A6
SIMCLK
O
External SIM signal – Clock
1.8 / 3V
A7
SIMRST
O
External SIM signal – Reset
1.8 / 3V
A5
SIMIO
I/O
External SIM signal – Data I/O
1.8 / 3V
A4
SIMIN
I
External SIM signal – Presence
(active low)
CMOS 1.8
A3
SIMVCC
-
External SIM signal – Power supply
for the SIM
1.8 / 3V
Analog Audio
B2
EAR+
O
Analog Audio Interface (EAR+)
Not available on UE910-
xxD/UE910-GL
