12.2 Digital Voice Interface
The UE910 Module is provided by one DVI digital audio interface.
12.2.1 Electrical Characteristics
The product is providing the Digital Voice Interface (DVI) on the following Pins:
Digital Voice Interface (DVI)
PAD
Signal
I/O
Function
Note
Type
B9
DVI_WA0
I/O
Digital Voice Interface (Word Alignment /
LRCLK)
CMOS 1.8V
B6
DVI_RX
I
Digital Voice Interface (RX)
CMOS 1.8V
B7
DVI_TX
O
Digital Voice Interface (TX)
CMOS 1.8V
B8
DVI_CLK
I/O
Digital Voice Interface (BCLK)
CMOS 1.8V
12.2.2 CODEC Examples
Please refer to the Digital Audio Application note.
