Telit Wireless Solutions UE910 series User Manual

Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 43 of 93
Sensitivity
UE910-EUR and UE910-EUD
UE910-NAR and UE910-NAD
UE910-GL
6.3 GSM/WCDMA Antenna Requirements
The antenna connection and board layout design are the most important aspect in the full
product design as they strongly affect the product overall performances, hence read carefully
and follow the requirements and the guidelines for a proper design.
The antenna and antenna transmission line on PCB for a Telit UE910 device shall fulfil the
following requirements:
ANTENNA REQUIREMENTS (UE910-EUR and UE910-EUD)
Frequency range
Depending by frequency band(s) provided by the network operator, the
customer shall use the most suitable antenna for that/those band(s)
Bandwidth (GSM/EDGE)
80 MHz in GSM900
170 MHz in DCS
Bandwidth
250 MHz in WCDMA Band I
Band
Typical
Note
GSM 900
-109 dBm
BER Class II <2.44%
DCS1800
-110 dBm
BER Class II <2.44%
WCDMA FDD B1
-111 dBm
BER <0.1%
WCDMA FDD B8
-110 dBm
BER <0.1%
Band
Typical
Note
GSM 850
-109.5 dBm
BER Class II <2.44%
PCS 1900
-109.5 dBm
BER Class II <2.44%
WCDMA FDD B2
-110 dBm
BER <0.1%
WCDMA FDD B5
-111 dBm
BER <0.1%
Band
Typical
Note
GSM 900
-109 dBm
BER Class II <2.44%
GSM 850
-109.5 dBm
BER Class II <2.44%
DCS1800
-110 dBm
BER Class II <2.44%
PCS 1900
-109.5 dBm
BER Class II <2.44%
WCDMA FDD B1
-111 dBm
BER <0.1%
WCDMA FDD B2
-110 dBm
BER <0.1%
WCDMA FDD B4, B5
-111 dBm
BER <0.1%
WCDMA FDD B8
-110 dBm
BER <0.1%
DRAFT
