WARNING
It is recommended to set the ON_OFF* line LOW to power on the module only after VBATT is higher
than 3.22V.
In case this condition it is not satisfied you could use the HW_SHUTDOWN* line to recover it and
then restart the power on activity using the ON_OFF * line.
An example of this is described in the following diagram:
