Tenda A18 User Manual

26
5 WiFi settings
This module allows you to change the repeater’s SSID and WiFi password, or to hide the repeater’s
SSID.
To access the page, choose WiFi Settings.
Parameter description
Parameter
Description
SSID
It specifies the wireless network name of the repeater.
WiFi Password
Password used for wireless network connection. You are recommended to use the
combination of digits, letters and special characters for higher security.
Hide
With this function enabled, wireless clients cannot detect the corresponding SSID, and
you need to manually enter the SSID on the wireless client to access the wireless
network. By default, this function is disabled.
No password
It indicates that a wireless network is not encrypted and any clients can access the
network without a password. This option is not recommended as it leads to low network
security.

Tenda A18 Specifications

General

Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	867 Mbit/s
Supported data transfer rates	11, 54, 300, 867 Mbps
Security algorithms	SSID, WPA-PSK, WPA-TKIP, WPA2-PSK
Product type	Network repeater
Product color	White
LED indicators	Power, Signal strength, WPS
DC input voltage	9 V
Power source type	DC
Power consumption (max)	5.2 W
Power consumption (typical)	2.8 W
Frequency band	2.412 - 2.484, 5.15 - 5.25 GHz
Channels quantity	2 channels
Transmission gain	12 - 16 dB
Receiver sensitivity	-97 dBm, -76 dBm, -74 dBm, -72 dBm, -95 dBm, -63 dBm
Antennas quantity	2
Antenna gain level (max)	2 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
RAM capacity	64 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Dimensions (WxDxH)	58 x 48 x 80 mm
