Tenda A18 User Manual

34
6.3 Switching the repeater from AP mode to
repeater mode
Configurations (except SSID and WiFi password you set) will be cleared when you switch from AP
mode to Repeater mode, and you need to configure your repeater again.
Configuration procedure:
Step 1 Choose Operating Mode to enter the configuration page.
Step 2 Click Repeater Mode.
Step 3 Click Switch Mode.
Step 4 Click OK on the page that appears.
Step 5 Wait until the progress bar is complete. Then reconfigure it to extend your existing WiFi
coverage.
---End

Tenda A18 Specifications

General

Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	867 Mbit/s
Supported data transfer rates	11, 54, 300, 867 Mbps
Security algorithms	SSID, WPA-PSK, WPA-TKIP, WPA2-PSK
Product type	Network repeater
Product color	White
LED indicators	Power, Signal strength, WPS
DC input voltage	9 V
Power source type	DC
Power consumption (max)	5.2 W
Power consumption (typical)	2.8 W
Frequency band	2.412 - 2.484, 5.15 - 5.25 GHz
Channels quantity	2 channels
Transmission gain	12 - 16 dB
Receiver sensitivity	-97 dBm, -76 dBm, -74 dBm, -72 dBm, -95 dBm, -63 dBm
Antennas quantity	2
Antenna gain level (max)	2 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
RAM capacity	64 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Dimensions (WxDxH)	58 x 48 x 80 mm
