7.3 Resetting the repeater
You are recommended to reset the repeater if you forget your login password, or you cannot
locate the problem that interrupts your repeater’s WiFi network service.
Resetting the repeater clears all configurations. You need to configure the repeater again.
To reset the repeater, use either of the following methods:
Method 1:
With the PWR LED indicator solid on, hold the RESET button down using a paper clip, and release
it when all the LED indicators blink once then turn off. Wait until the PWR LED indicator lights solid
on again, the repeater is reset successfully.
Method 2:
Step 1 Log in to the web UI of the repeater, choose Administration.
Step 2 Click Reset.
Step 3 Click Reset on the popup window.
---End
Wait a moment until the progress bar is complete. You need to reconfigure the repeater.

Tenda A18 Specifications

General

Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	867 Mbit/s
Supported data transfer rates	11, 54, 300, 867 Mbps
Security algorithms	SSID, WPA-PSK, WPA-TKIP, WPA2-PSK
Product type	Network repeater
Product color	White
LED indicators	Power, Signal strength, WPS
DC input voltage	9 V
Power source type	DC
Power consumption (max)	5.2 W
Power consumption (typical)	2.8 W
Frequency band	2.412 - 2.484, 5.15 - 5.25 GHz
Channels quantity	2 channels
Transmission gain	12 - 16 dB
Receiver sensitivity	-97 dBm, -76 dBm, -74 dBm, -72 dBm, -95 dBm, -63 dBm
Antennas quantity	2
Antenna gain level (max)	2 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
RAM capacity	64 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Dimensions (WxDxH)	58 x 48 x 80 mm
