Tenda A18 User Manual

45
A.2 Default parameter values
The following table lists the default parameter values of the repeater.
Parameter
A18&A15
Login address
re.tenda.cn/192.168.0.254
Login password
None
Operating mode
Repeater mode
IP address
192.168.0.254
After expanding the network of the WiFi router successfully, the
repeater obtains an IP address automatically from the DHCP server of
the upstream device.
Subnet mask
255.255.255.0
After expanding the network of the WiFi router successfully, the
repeater obtains a subnet mask automatically from the DHCP server
of the upstream device.
DHCP server status
Enabled
It depends on whether the DHCP server is enabled of the upstream
device. If the repeater expands the network of WiFi router
successfully, the DHCP server will be disabled. Otherwise, it will be
enabled.
SSID
Tenda_EXT
WiFi password
None

Tenda A18 Specifications

General

Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	867 Mbit/s
Supported data transfer rates	11, 54, 300, 867 Mbps
Security algorithms	SSID, WPA-PSK, WPA-TKIP, WPA2-PSK
Product type	Network repeater
Product color	White
LED indicators	Power, Signal strength, WPS
DC input voltage	9 V
Power source type	DC
Power consumption (max)	5.2 W
Power consumption (typical)	2.8 W
Frequency band	2.412 - 2.484, 5.15 - 5.25 GHz
Channels quantity	2 channels
Transmission gain	12 - 16 dB
Receiver sensitivity	-97 dBm, -76 dBm, -74 dBm, -72 dBm, -95 dBm, -63 dBm
Antennas quantity	2
Antenna gain level (max)	2 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
RAM capacity	64 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Dimensions (WxDxH)	58 x 48 x 80 mm
