Tenda A27 User Manual

Version1.0
42
Parameter
Description
WiFi name
It specifies the wireless network name of the WiFi extender.
Hide
With this function enabled, no WiFi enabled device can find the corresponding WiFi
name, and you need to manually enter the WiFi name on the WiFi enabled device to
access the wireless network.
By default, this function is disabled.
Security
The WiFi extender supports the following security modes:
- Not encrypted: The WiFi extender does not encrypt its wireless network. This option
is not recommended because it affects network security.
- WPA2-PSK (Recommended): The wireless network is encrypted with
WPA2-PSK which adopts a pre-shared key for authentication. Therefore, wireless
networks encrypted with WPA2-PSK are safer than those encrypted with WAP-PSK.
- WPA3-SAE/WPA2-PSK: The wireless network is encrypted with both WPA2-PSK/AES
and WPA3-SAE/AES, improving its security. With Simultaneous Authentication of Equals
(SAE) and Protected Management Frames (PMF), WPA3-SAE can defend dictionary
attacks and prevent information leakage without requiring users to set complex
passwords.
WPA3-SAE is the upgraded version of WPA2-PSK. If your WiFi enabled devices do not
support the WPA3-SAE or you have a poor WiFi experience, you are recommended to
switch the security mode back to WPA2-PSK (Recommended).
WiFi Password
It specifies the password used for wireless network connection.
You are recommended to use the combination of digits, letters and special characters for
higher security.

Tenda A27 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ax
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	2
Antenna gain level (max)	5 dBi
DC input voltage	12 V
DC output current	1 A
Power source type	DC
Power consumption (max)	11 W
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency band	2.412-2.484, 5.15-5.25, 5.725-5.85 GHz
Output power (dBm)	2.4GHz (2412 MHz~2472 MHz):19.97dBm 5GHz (5150 MHz~5250 MHz; 5250 MHz~5350 MHz; 5470 MHz~5725 MHz):22.99dBm
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Receiver sensitivity	2.4 GHz 11b-1M:-97dBm 11g-54M:-76dBm 11n-20M-MCS7:-74dBm 11n-40M-MCS7:-72dBm 5 GHz: 11a-6M:-95dBm 11n-20M-MCS7:-74dBm 11n-40M-MCS7:-72dBm 11ac-80M-MCS9:-63dBm
WLAN data transfer rate (max)	1800 Mbit/s
Security algorithms	WPA-PSK, WPA-TKIP, WPA2-PSK, WPA3
Product type	Network repeater
Product color	White
Quantity per pack	1 pc(s)
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Certification	CE, FCC、RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	72 mm
Width	123 mm
Height	47.5 mm
