Tenda A33 User Manual

Version1.0
16
Method 2: Extend your WiFi networks using WPS
If your WiFi router has a WPS button, which may be indicated by , , or , or support
Tenda WiFi + Mesh technology, this method is recommended to extend WiFi networks, sparing the
trouble to enter WiFi password. Otherwise, use Method 1.
Step 1 Plug the WiFi extender into a power outlet near the router in the same room. Wait until
the LED indicator turns blinking red.
Step 2 Extend your WiFi network.
Press the WPS button on the router to enable the WPS function. 1.
Press the WPS button on the WiFi extender within 2 minutes. The LED indicator will blink 2.
red quickly.
When the LED indicator on the WiFi extender turns solid on, the network is extended
successfully.
WiFi router
LED indicator blinks red

Tenda A33 Specifications

General

Maximum data transfer rate	1000 Mbit/s
Antennas quantity	2
Antenna gain level (max)	5 dBi
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency band	5/2.4 GHz
Signal strength	20 dBm
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2402 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA-PSK, WPA2-PSK, WPA3
Power LED	No
Product type	Network repeater
Product color	White
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	CE, RoHS
Certification	FCC
DC output current	1 A
DC output voltage	12 V
Power consumption (typical)	11 W

Weight and Dimensions

Depth	72 mm
Width	123 mm
Height	47.5 mm
