Tenda O3 User Manual

137
Parameters Description
Name
Description
Remote Web Management
It specifies whether to enable the remote web management function.
IP Address
It specifies the IP address of a device which is allowed to access the web UI of the CPE.
All: It indicates that any computer in WAN can manage this device remotely. For security, it is not
recommended.
Manual: It indicates that only the device with specified IP address can manage this device
remotely. If this device belongs to a LAN, the gateway address (a public IP address) of the device
should be entered.
Port
It specifies the port number used for remote management of device. Default: 8080. You can
change it if necessary.
Port s1 to 1024 have been used by well-known services. To avoid port conflict, you can set the
port number to one between 1025 and 65535. Then you can access the device from WAN by
visiting an address in the form of http://WAN IP address:port number. If the DDNS function is
enabled on the device, you can access the device by visiting an address in the form of
http://Domain name of WAN port:port number.
Examples of Configuring Remote Web Management
Networking Requirement
The CPE is used in a company to deploy its network, and it works in Router mode.
Requirement: The administrator needs to maintenance the network when he is on business. So he needs to
access the device’s web UI on WAN.
You are recommended to use the remote web management function to solve the problem.
Assumption:
− The WAN IP address of the CPE is 202.105.106.55
− The IP address of the computer which is allowed to access the device on WAN is 202.105.88.77
− Port number is 8080
Configuration Procedure
Step 1 Log in to the web UI of the CPE.
Step 2 Choose Advanced > Network Service.
Step 3 Enable the Remote Web Management function.
Step 4 Set IP Address to Manual.
Step 5 Enter the IP address of the computer which is allowed to access the CPE on WAN, which is
202.105.106.55 in this example.
Step 6 Enter the port number, which is 8080 in this example.
Step 7 Click Save in the bottom of this page.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
