Tenda O3 User Manual

148
9 Tools
9.1 Date & Time
This module enables you to set the system time of the CPE.
Ensure that the system time of the CPE is correct, so that logs can be recorded correctly and the reboot schedule
can be executed correctly.
Choose Tools > Date & Time to enter the page.
The CPE allows you to set the system time by synchronizing the time with the internet or manually setting the
time. By default, it is configured to synchronize the system time with the internet.
Synchronized with the Internet
The CPE automatically synchronizes its system time with a time server of the internet. This enables the CPE to
automatically correct its system time after being connected to the internet.
For details about how to connect the CPE to the internet, refer to LAN Setup.
Configuration Procedure
Step 1 Choose Tools > Date & Time.
Step 2 Set Time settings to Synchronized with the Internet.
Step 3 Specify a time interval. The default value 30 minutes is recommended.
Step 4 Set Time Zone to your time zone.
Step 5 Click Save.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
