Tenda O3 User Manual

79
The following form shows the configuration on the switch:
Ports of the Switch
VLAN ID (Allow the packets belonging to
the following VLANs to access)
Type of Port
PVID
Uplink port (Connected to a
router)
1,10,20
Trunk
1
Port 1 (Connected to CPE1)
1,10
Trunk
1
Port 3 (Connected to CPE2)
1,20
Trunk
1
Keep the default settings for the parameters which are not mentioned here. Refer to the user guide of the switch
for details.
The following form shows the configuration on the router:
Port of the router is
connected to
VLAN ID (Allow the packets belonging to
the following VLANs to access)
Type of Port
PVID
The switch
10, 20
Trunk
1
Refer to the user guide of the router for details.
----End
Verification
If the router enables two DHCP servers which belong to VLAN10 and VLAN20 respectively, the first device
connected to the CPE obtains an IP address and related parameters from the DHCP server belonging to VLAN10,
and the second device obtains these parameters from the DHCO sever belonging to VLAN20.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
