Tenda O3 User Manual

82
----End
Parameters Description
Name
Description
Enable Wireless
It specifies whether to enable the wireless function. By default, it is enabled.
Country/Region
It specifies country or region where this device is located. You can select the country or region to
ensure that this device complies with the channel regulations of the country or region.
SSID
It specifies the wireless network name.
Broadcast SSID
It specifies whether to broadcast the SSID.
Enable indicates that the SSID is broadcast and nearby wireless devices can find the SSID.
Disable indicates that the SSID is not broadcast and nearby wireless devices cannot find the SSID.
Network Mode
It specifies the network mode of this device. The available options include 11b/g, 11b, 11g, and
*
*
*

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
