Tenma 72-3540 - Conductance, Temp, Freq, Duty Cycle Accuracy

12
CONDUCTANCE
Range Resolution Accuracy tolerance: ± (% reading + digits)
60NS 0.01NS ± (2% + 10)
• Overload protection: 1,000V.
• Humidity for 60MΩ: <50%.
TEMPERATURE
Range Resolution Accuracy tolerance: ± (% reading + digits)
-40°C~40°C
0.1
± (2.0% + 30)
40°C~400°C ± (1.0% + 30)
400°C~1000°C ± 2.5%
-40°F~104°C
0.2°F
± (2.5% + 50)
104°F~752°F ± (1.5% + 50)
752°F~1832°F ± 2.5%
• Overload protection: 1000V.
• Two-channel temperature measurement can be performed via temperature
connectors.
• Temperature sensor: Applicable to K-type thermocouple. Spare parts are
point contact K-type thermocouple (only applicable to the measurement when
temperature is below 230°C).
FREQUENCY
Range Resolution Accuracy
60Hz 0.001Hz ± (0.02% + 8)
600Hz 0.01Hz
± (0.01% + 5)
6kHz 0.0001kHz
60kHz 0.001kHz
600kHz 0.01kHz
6MHz 0.0001MHz
60MHz 0.001MHz
• Overload protection: 1000V.
• Input amplitude: 10Hz~30MHz:
600mV ≤ a ≤ 30Vrm.
Greater than 30MHz: not specified.
DUTY CYCLE
Range Resolution Accuracy tolerance: ± (% reading + digits)
10%~90%
(10Hz~2KHz)
0.01% ± (1.2% + 30)
